Apollo 816 LA Linear Actuator
Installation Reference Manual
1212
6
RUN ACTUATOR CABLE(S) TO CONTROL BOX
1. Run the cable of the actuator closest to the control box through a hole (with rubber grommet) drilled in the
bottom on the control box. If necessary, entry may be made elsewhere on the control box.
2. If a dual gate installation:
3. Dig a trench across the driveway deep enough to accommodate the longer harness cable from the
actuator farthest from the control box.
4. Run the cable through an appropriate conduit and lay this in the trench.
5. Cover the trench and use asphalt patch if needed.
6. Run the 2nd cable into a hole (with rubber grommet) into the bottom of the control box.
NOTICE
Ensure the cable(s) reaches into the control box su󰀩ciently to reach the MOTOR inputs on the control
board.
