CBOX1050
Installation and Programming Manual
3838
support.hysecurity.com
Press
DELAY
1. Auto Close :0.0
DELAY
2. Secondary
:0.0
DELAY
3. Lamp :0.0
DELAY
4. Lock :5.0
DELAY
5. ESC
DELAY
EXIT
OK
DELAY Button
OK
0 SEC.
90 SEC.
OK
0 SEC.
5 SEC.
OK
0 SEC.
5 SEC.
OK
0 SEC.
5 SEC.
DELAY BUTTON MENU:
• AUTO CLOSE: Sets the time before the gate closes automatically from the fully open position. Settings
from 0 (o) to 90 seconds. Setting this to 0 will disable the auto close timer.
• SECONDARY: Enables overlapping dual gates to dovetail smoothly by creating a momentary delay for
Secondary operator when opening and Primary when closing. Settings from 0-5 seconds with increments
of 0.5.
Example: If 03 is selected, in the OPEN direction the Secondary operator will begin to OPEN 3 seconds
after the Primary. In the CLOSE direction the Primary operator will begin to CLOSE 3 seconds after the
Secondary.
• LAMP/STROBE: Sets the amount of time the Lamp accessory output is activated prior to gate movement.
Settings from 0 to 5 seconds with a step of 0.5 seconds.
• LOCK: Sets the amount of time the Magnetic Lock accessory output is activated to disable the lock when
opening the gate. Settings from 0 to 5 seconds with a step of 0.5 seconds.
• ESC: Exit the DELAY menu.
NOTICE
The Remote Primary/Secondary setting must be turned on for 24V commercial operators in the
Advanced Settings menu and each operator defined as Primary or Secondary. For 12V residential
operators the Primary is Motor 1 by default but can be changed in the Advance Settings menu.
