Green trafc light (0x0e) This function indicates activity of the application during the phases of an Opening manoeuvre.
slow ashing = execution of Opening manoeuvre;
light permanently on = application in maximum Opening position;
light off = application in other positions.
One way trafc light (0x1a) This function requires the XBA8 asher, and operates as follows: - With the pole up, green - In all other cases, red.
Note: if pre-ashing is active, the start of the manoeuvre is preceded by the red signal ashing.
Two-way alternating trafc light
(0x1a)
This function requires the XBA8 asher, and operates as follows: When an open command is sent from inside, the
inwards green light and outwards red light are activated, thus giving priority to the person inside. When an open
command is sent from outside, the inwards green light and the outwards red light are activated, thus giving priority to
the person outside. When the door is closed or closing, the signal is red in both directions. For the system to oper-
ate in this mode, the commands must be sent to the control unit as follows: - Inside commands: Input 2 or Loop1
congured as open - Outside commands: Input 3 or Loop2 congured as open
One way trafc light for pedestri-
ans (0x21)
This function requires the XBA8 asher, and operates as follows:
- pole closed: green inside, red outside
- pole open: red inside, green outside
- pole in other positions: red inside and outside
Radio channel 1 (0x0f) When a transmitter sends a command, this output is activated. This mode is useful if installing external devices (for
example, an auxiliary light) in the same system to be controlled with a single transmitter. CAUTION – If this channel
is not free on the control unit's receiver, due to having been previously memorised with a command, when the chan-
nel is activated by the transmitter, the control unit only activates the programmed output, and ignores the motor
command.
Radio channel 2 (0x10) When a transmitter sends a command, this output is activated. This mode is useful if installing external devices (for
example, an auxiliary light) in the same system to be controlled with a single transmitter. CAUTION – If this channel
is not free on the control unit's receiver, due to having been previously memorised with a command, when the chan-
nel is activated by the transmitter, the control unit only activates the programmed output, and ignores the motor
command.
Radio channel 3 (0x11) When a transmitter sends a command, this output is activated. This mode is useful if installing external devices (for
example, an auxiliary light) in the same system to be controlled with a single transmitter. CAUTION – If this channel
is not free on the control unit's receiver, due to having been previously memorised with a command, when the chan-
nel is activated by the transmitter, the control unit only activates the programmed output, and ignores the motor
command.
Radio channel 4 (0x12) When a transmitter sends a command, this output is activated. This mode is useful if installing external devices (for
example, an auxiliary light) in the same system to be controlled with a single transmitter. CAUTION – If this channel
is not free on the control unit's receiver, due to having been previously memorised with a command, when the chan-
nel is activated by the transmitter, the control unit only activates the programmed output, and ignores the motor
command.
Output 1 (ash)
In this output the user can select one of the functions specied in Table 3.
TABLE 3: OUTPUT CONFIGURATION
FUNCTION DESCRIPTION
Not specied The output is never activated
sca (= gate/barrier open) The programmed light indicates the operating status of the control unit.
light off = application in maximum Closing position;
slow ashing = application Opening manoeuvre execution phase;
quick ashing = application Closing manoeuvre execution phase;
light permanently on = application in maximum Opening position.
Output active 24 V DC / max 10 W
Sca1 The programmed light indicates the operating status of the control unit.
light permanently on = application in maximum Opening or maximum Closing position;
slow ashing = application Opening manoeuvre execution phase;
quick ashing = application Closing manoeuvre execution phase;
light off = application stationary, in a different position than maximum Closing or maximum Opening.
Output active 24 V DC / max 10 W
Sca2 The programmed light indicates the operating status of the control unit.
light permanently on = application in maximum Closing position;
slow ashing = application Opening manoeuvre execution phase;
quick ashing = application Closing manoeuvre execution phase;
light off = application stopped in maximum Opening position.
Output active 24 V DC / max 10 W
gate open The programmed light indicates the operating status of the control unit.
light on = application in maximum Opening position;
light off = application in other positions.
Output active 24 V DC / max 10 W
gate closed The programmed light indicates the operating status of the control unit.
light on = application in maximum Closing position;
light off = application in other positions.
Output active 24 V DC / max 10 W
maintenance indicator light The programmed light indicates the count of manoeuvres completed and therefore the need (or not) for system
maintenance operations.
light on for 2 sec at start of Opening manoeuvre = number of manoeuvres less than 80%;
light ashing during execution of entire manoeuvre = number of manoeuvres between 80 and 100%;
light always ashing = number of manoeuvres over 100%.
