Nice MBar User Manual

ashing light This function enables the asher to indicate execution of a manoeuvre in progress with ashes at regular intervals
(0,5 sec. ON; 0,5 sec. OFF).
Output active 12 Vdc / max 21 W
Flasher 1 This function enables the asher to ash constantly at regular intervals (0.5 sec ON; 0,5 sec. OFF) both during a
manoeuvre and when the pole is stationary.
Output active 24 V DC / max 10 W
24V asher This function enables the ashing light to indicate execution of a manoeuvre in progress with ashes at regular
intervals (0.5 sec ON, 0.5 sec OFF).
Output active 24 V DC / max 10 W
courtesy light This function type is ON/OFF. Important – For safety reasons, as the light is not controlled by a timer, use of an
adequate light, able to withstand the heat of the light emitted, is recommended.
Output active 24 V DC / max 10 W
Always on This function enables the indicator light to remain constantly lit both during a manoeuvre and when the pole is
stationary.
Output active 24 V DC / max 10 W
electric lock 1 With this function programmed, when an Opening manoeuvre is performed the electric lock is activated for a time
as set in the function “electric lock time – output conguration”.
Output active 24 V DC / max 10 W
electric block 1 With this function programmed, when an Opening manoeuvre is performed the electric lock is activated for a time
as set in the function “electric lock time – output conguration”.
Output active 24 V DC / max 10 W
suction cup 1 With this function programmed, the suction cup is activated when the application is in the maximum Closing posi-
tion. Note – The suction cup is disabled in all other situations. When the suction cup is disabled, before an Opening
manoeuvre is started, the time interval as programmed in the function “suction cup time – output conguration” is
activated, which delays the start of the manoeuvre.
Output active 24 V DC / max 10 W
red trafc light This function indicates activity of the application during the phases of a Closing manoeuvre.
slow ashing = execution of Closing manoeuvre;
light permanently on = application in maximum Closing position;
light off = application in other positions.
Output active 24 V DC / max 10 W
green trafc light This function indicates activity of the application during the phases of an Opening manoeuvre.
slow ashing = execution of Opening manoeuvre;
light permanently on = application in maximum Opening position;
light off = application in other positions.
Output active 24 V DC / max 10 W
radio channel no.1 If this radio channel is set for the conguration of output 1 (ash), this channel is activated when a command is set
with the transmitter. It is useful if installing external devices (for example, an auxiliary light) in the same system to be
controlled with a single transmitter. CAUTION – If this channel is not free on the control unit's receiver, due to having
been previously memorised with a command, when the channel is activated by the transmitter, the control unit only
activates the programmed output, and ignores the motor command.
Output active 24 V DC / max 10 W
radio channel no.2 If this radio channel is set for the conguration of output 1 (ash), this channel is activated when a command is
set with the transmitter. This mode is useful if installing external devices (for example, an auxiliary light) in the same
system to be controlled with a single transmitter. CAUTION – If this channel is not free on the control unit's receiver,
due to having been previously memorised with a command, when the channel is activated by the transmitter, the
control unit only activates the programmed output, and ignores the motor command.
Output active 24 V DC / max 10 W
radio channel no.3 If this radio channel is set for the conguration of output 1 (ash), this channel is activated when a command is
set with the transmitter. This mode is useful if installing external devices (for example, an auxiliary light) in the same
system to be controlled with a single transmitter. CAUTION – If this channel is not free on the control unit's receiver,
due to having been previously memorised with a command, when the channel is activated by the transmitter, the
control unit only activates the programmed output, and ignores the motor command.
Output active 24 V DC / max 10 W
radio channel no.4 If this radio channel is set for the conguration of output 1 (ash), this channel is activated when a command is
set with the transmitter. This mode is useful if installing external devices (for example, an auxiliary light) in the same
system to be controlled with a single transmitter. CAUTION – If this channel is not free on the control unit's receiver,
due to having been previously memorised with a command, when the channel is activated by the transmitter, the
control unit only activates the programmed output, and ignores the motor command.
Output active 24 V DC / max 10 W
Loop1 This output copies the status of the command coming from Loop1, per the current settings.
Output active 24 V DC / max 10 W
Loop2 This output copies the status of the command coming from Loop2, per the current settings.
Output active 24 V DC / max 10 W
output 2
This output can be set to one fo the functions described in Table 3, including those described below
Buzzer/Siren (0x1d) This function activates the output (siren) when the amperometric force limiter trips twice during a given manoeuvre.
The barrier locks and accepts no further commands. The siren sounds for 5 minutes; it then deactivates but the
barrier stays locked.
To release the barrier press the control unit’s STOP button, or actuate the device connected to the control unit’s
STOP input.
Output active 24 V DC / max 10W
