Nice NDA001 - Page 11

Green trafc light (0x0e) This function indicates activity of the application during the phases of an
Opening manoeuvre.
slow ashing = execution of Opening manoeuvre;
light permanently on = application in maximum Opening position;
light off = application in other positions.
The OUT-TL3 output at 24V DC / max 5W is used
One way trafc light (0x1a) This function operates as follows:
OUT-TL2 and OUT-TL3 are active when the door is open, and deactivated in
all other conditions.
The function uses outputs OUT-TL2 and OUT-TL3 at 24V / 5W
One-way trafc light ashing (0x1b) This function operates as follows:
OUT-TL2 ashes when opening and stays active with the door open, deacti-
vated in all other conditions.
OUT-TL3 ashes when closing and stays active with the door stationary in any
position other than fully open; deactivated in all other conditions.
The function uses outputs OUT-TL2 and OUT-TL3 at 24V / 5W
Two-way alternating trafc light (0x1a) This function operates as follows:
When an open command is sent from inside, OUT-TL2 (green trafc light) is
activated, giving priority to the person inside.
When an open command is sent from outside, OUT-TL3 (green trafc light) is
activated, giving priority to the person outside.
When the door is closed or closing, both trafc lights are deactivated (red
trafc light).
For the system to operate in this mode, the commands must be sent to the
control unit as follows:
Commands from inside: Input 2 congured as Open
Commands from outside: Input 3 congured as Open
The function uses outputs OUT-TL2 and OUT-TL3 at 24V / 5W
Door status (0x1e) This function operates as follows:
When the door is closed, OUT-TL1 is activated and all others remain off.
When the door is open, OUT-TL2 is activated and all others remain off.
When a door is in any position other than fully open or closed, OUT-TL3 is
activated and all others remain off.
The function uses outputs OUT-TL1, OUT-TL2 and OUT-TL3 at 24V / 5W
sca (0x01) The programmed light indicates the operating status of the control unit.
light off = application in maximum Closing position;
slow ashing = application Opening manoeuvre execution phase;
quick ashing = application Closing manoeuvre execution phase;
light permanently on = application in maximum Opening position.
The OUT-TL1 output at 24V DC / max 5 W is used
Gate open (0x02) The programmed light indicates the operating status of the control unit.
light on = application in maximum Opening position;
light off = application in other positions.
The OUT-TL1 output at 24V DC / max 5 W is used
Gate closed (0x03) The programmed light indicates the operating status of the control unit.
light on = application in maximum Closing position;
light off = application in other positions.
The OUT-TL1 output at 24V DC / max 5 W is used
Service light (0x04) The programmed light indicates the count of manoeuvres completed and
therefore the need (or not) for system maintenance operations.
light on for 2 sec at start of Opening manoeuvre = number of manoeuvres
less than 80%;
light ashing during execution of entire manoeuvre = number of manoeuvres
between 80 and 100%;
light always ashing = number of manoeuvres over 100%.
The OUT-TL1 output at 24V DC / max 5 W is used
Flasher at 24V (0x17) This function enables the ashing light to indicate execution of a manoeuvre in
progress with ashes at regular intervals (0.5 sec ON, 0.5 sec OFF).
The OUT-TL2 output at 24V DC / max 5 W is used
Electric lock 1 (0x07) With this function programmed, when an Opening manoeuvre is performed
the electric lock is activated for a time as set in the function “electric lock time
– output conguration”.
The OUT-TL2 output at 24V DC / max 5 W is used
Electric block 1 (0x09) With this function programmed, when an Opening manoeuvre is performed
the electric lock is activated for a time as set in the function “electric lock time
– output conguration”.
The OUT-TL2 output at 24V DC / max 5 W is used
