Suction cup 1 (0x0b) With this function programmed, the suction cup is activated when the appli-
cation is in the maximum Closing position. Note – The suction cup is disabled
in all other situations. When the suction cup is disabled, before an Opening
manoeuvre is started, the time interval as programmed in the function “suc-
tion cup time – output conguration” is activated, which delays the start of
the manoeuvre.
The OUT-TL2 output at 24V DC / max 5 W is used
Courtesy light (0x06) This function type is ON/OFF. Important – For safety reasons, as the light is
not controlled by a timer, use of an adequate light, able to withstand the heat
of the light emitted, is recommended.
The OUT-TL3 output at 24V DC / max 5 W is used
Radio channel 1 (0x0f) When a transmitter sends a command, this output is activated. This mode is
useful if installing external devices (for example, an auxiliary light) in the same
system to be controlled with a single transmitter. CAUTION – If this channel is
not free on the control unit's receiver, due to having been previously memo-
rised with a command, when the channel is activated by the transmitter, the
control unit only activates the programmed output, and ignores the motor
command.
The OUT-TL3 output at 24V DC / max 5 W is used
Radio channel 2 (0x10) When a transmitter sends a command, this output is activated. This mode is
useful if installing external devices (for example, an auxiliary light) in the same
system to be controlled with a single transmitter. CAUTION – If this channel is
not free on the control unit's receiver, due to having been previously memo-
rised with a command, when the channel is activated by the transmitter, the
control unit only activates the programmed output, and ignores the motor
command.
The OUT-TL3 output at 24V DC / max 5 W is used
Radio channel 3 (0x11) When a transmitter sends a command, this output is activated. This mode is
useful if installing external devices (for example, an auxiliary light) in the same
system to be controlled with a single transmitter. CAUTION – If this channel is
not free on the control unit's receiver, due to having been previously memo-
rised with a command, when the channel is activated by the transmitter, the
control unit only activates the programmed output, and ignores the motor
command.
The OUT-TL3 output at 24V DC / max 5 W is used
Radio channel 4 (0x12) When a transmitter sends a command, this output is activated. This mode is
useful if installing external devices (for example, an auxiliary light) in the same
system to be controlled with a single transmitter. CAUTION – If this channel is
not free on the control unit's receiver, due to having been previously memo-
rised with a command, when the channel is activated by the transmitter, the
control unit only activates the programmed output, and ignores the motor
command.
The OUT-TL3 output at 24V DC / max 5 W is used
output 1 (ash)
In this output the user can select one of the functions specied in Table 2.
TABLE 2: OUTPUT CONFIGURATION
MODE DESCRIPTION
Not specied The output is never activated
sca (= gate open indicator) The programmed light indicates the operating status of the control unit.
light off = application in maximum Closing position;
slow ashing = application Opening manoeuvre execution phase;
quick ashing = application Closing manoeuvre execution phase;
light permanently on = application in maximum Opening position.
Output active 24 Vdc / max 10 W
Sca1 The programmed light indicates the operating status of the control unit.
light permanently on = application in maximum
Opening or Closing position;
slow ashing = application Opening manoeuvre execution phase;
quick ashing = application Closing manoeuvre execution phase;
light off = application stationary, in a different position than maximum Closing
or maximum Opening.
Output active 24 V DC / max 10 W
Sca2 The programmed light indicates the operating status of the control unit.
light permanently on = application in maximum Closing position;
slow ashing = application Opening manoeuvre execution phase;
quick ashing = application Closing manoeuvre execution phase;
light off = application stopped in maximum Opening position.
Output active 24 V DC / max 10 W
gate open The programmed light indicates the operating status of the control unit.
light on = application in maximum Opening position;
light off = application in other positions.
Output active 24 Vdc / max 10 W
