English – 6
4
1 2 3 4 1 2 3 4 4 3 2 1 1 2 3 4
3
Oview is only activated when connected to a live device, as it is powered
directly by the latter.
On activation of Oview, the icon representing the connected device is displayed
on screen.
• Key to Oview keys
Oview comprises the following parts ( g. 6):
1 LCD screen;
2 / 4 Arrow keys W and X: used to move from one eld to another in a
window and to move from one window to another;
3 / 5 Arrow keys S and T: used to modify values in a selected eld or to
scroll within a list;
6 Key used to con rm a value;
7 Key z used to select the item displayed at the bottom left of the screen
(9);
8 Key z used to select the item displayed at the bottom right of the
screen (10).
• Oview home page
After activating Oview, the application home page is displayed. This window
comprises the following elements (see g. 7):
A Name of selected device.
B Icon de ning the type of device connected; in the case of a network of
devices the screen displays the rst device found.
C Number indicating the series to which the selected device belongs.
D Local time and date.
E Menu”: this enables the user to access all functions available to program
a device.
F Options”: this enables the user to access all functions available to con-
trol one or more devices and con gure Oview.
GENERAL USE OF OVIEW
4
5
EN
