Nice UST1K User Manual

8–English
EN
Electronic limit switches
Six-pole plug
Control unit connection cable
A type
Wires 1, 2 and 3
Control unit
connection cable
h
Six-pole plug
Control unit connection cable
h
Electronic limit switches
B type
h
Five-pole
multiple
adapter
Control unit
connection
cable
rotoMWire Control station
U1U/1J - 2X
V2V/1J - 2X
W3W/1J - 2X
-Jumper6J - 2X
9J - 3S422J - 5X
9J - 3S522J - 5X
1P0112J - 5X ↓ - J3/C
1P1112J - 5X ↓ - J3/NC
E602J - 5X ↑ - J2
E702J - 5X ↑ - J2
E891J - 5X ↓ - J4
E991J - 5X ↓ - J4
PE terminal Yellow/green PE
L1
L1
L1
1
2
3
4
5
6
7
8
9
N
N
N
Contact with zero
potentialforredtrafc
lights
Contact with zero
potentialforuppernal
position signalling
Contact with zero
potential for lower
nalpositionsignalling
7
2
4
6
9 108
1
3
5
11 12
Wago terminal
AMP plug
Safety chain
Input
RS485B
GND
RS485A
Safety chain
Output
7..18VDC
12
13
14 15
16
