Nice WIDE L - General Safety Warnings and Precautions; General Warnings; Installation Warnings

2
Introducon.
Page 3 Be Safe! Instrucons, warnings and obligaons.
Page 4 Technical specicaons.
Page 5 Component idencaon and descripons.
Site preparaon.
Page 6 Pole lengths (limitaons) and pole accessory kits.
Page 7 Calculang the duty cycle.
Page 7 Posioning the barrier.
Page 8 Typical cabling requirements.
Hardware installaon - Mechanical.
Page 9 Baseplate kit and installing the baseplate.
Page 10 Opening the cabinet.
Page 10 Mounng onto the baseplate.
Page 11 How to use the manual override.
Page 11 Changing the handedness of the barrier.
Page 12 Aaching the boom pole mounng to the output sha.
Page 13 Checking and adjusng the spring balancing.
Hardware installaon - Electrical.
Page 14 Terminang the AC supply.
Page 15 Wiring and terminaon of the control card.
Page 16 Adjusng the slow down switches.
Control card programming and setup.
Page 17 Programming menu quick reference guide.
Page 18 Seng up the barrier runme.
Page 19 Selecng a safety level.
Page 19 Safety infra-red beams setup.
Page 20 Selecng a BT operang mode and adjusng the BT auto-close me.
Page 22 Receiver programming and setup.
Page 29 Advance programming opons and their denions.
Operang mode denions and examples.
Page 31 Collision sensing and safety overload rounes
Page 32 “BM” Safety infra-red beams funcon.
Page 33 “BT” Buon triggers - Simplexmode.
Page 34 “BT” Buon triggers - Simplex auto-close mode.
Page 35 “BT” Buon triggers - Complex auto-close mode.
Page 36 “OPEN” Open only triggers.
Page 37 “E-STOP” Emergency stop triggers.
Page 38 Auxiliary relay modes - Strike lock mode.
Page 39 Auxiliary relay modes - Magnec lock mode.
Page 40 Auxiliary relay modes - Courtesy light mode.
Page 41 Auxiliary relay modes - Receiver relay mode.
Page 42 Auxiliary relay modes - Trac light mode.
Page 43 Holiday lock-out mode.
Page 44 Auto-close override/party mode.
Page 45 Tamper alarms.
Troubleshoong.
Page 48 Status LED, buzzer and diagnoscs menu denions.
Page 50 Troubleshoong guide and display denions.
Page 53 Warranty.
For any assistance with this product that is not covered in this manual please contact us on: 0860 109 238 (RSA) or via our online
support facility at www.etnice.co.za.
