Nice WIDE L - Cabling Requirements

7
Cabling requirements.
• Before mounng the operator ensure your cables and conduing are in place to prevent any inconvenience at a later stage.
• All 220Vac mains cabling and circuits need to be installed by a qualied electrician and signed o by a registered electrician.
• Allow for spare cabling in case of faulty cable & breakages (especially important when using low specicaon cable).
• As automaon systems vibrate when in use, it is highly recommended that only mul-stranded, exible cables be used.
• If installing an intercom, remember to allow for sucient cable cores for all the users of the system as per manufacturers cabling requirements.
1. Courtesy lights. Twin + earth 1.0mm back to control card and
isolator switch.
5. Infra-red safety beam RX. 3 core 0,5mm stranded back to barrier
housing.
2. Intercom barrier staon (check with intercom supplier for cable
specicaons)
6. Infra-red safety beam TX. 2 core 0,5mm stranded back to barrier
housing.
3. Double pole single throw 20A isolator. Twin + earth 2.5mm
between 220V mains supply and PSU in control unit.
7. Free exit loop 1.5mm silicone insulated single core exible stranded
cable back to loop detector that is typically installed in the barrier
housing.
4. Stop/go trac LED trac light. 3 core 0,5mm stranded back to
barrier housing.
8. From automated spikes 2 x 2,5mm and 3 x 0,5mm stranded exible
stranded cable back to barrier housing.
1
2
4
3
8
7
6
4
5
