Nietz SSN Series User Manual

NIetz Electric Co.,Ltd Soft starter SSN/SSA serie User Manual
32
132 260 SSN-132-3 SSA-132-3 SSN-132G-3
160 320 SSN-160-3 SSA-160-3 SSN-160G-3
187 375 SSN-187-3 SSA-187-3 SSN-187G-3
200 400 SSN-200-3 SSA-200-3 SSN-200G-3
250 480 SSN-250-3 SSA-250-3 SSN-250G-3
280 550 SSN-280-3 SSA-280-3 SSN-280G-3
320 620 SSN-320-3 SSA-320-3 SSN-320G-3
400 780 SSN-400-3 SSA-400-3 SSN-400G-3
450 850 SSN-450-3 SSA-450-3 SSN-450G-3
500 1000 SSN-500-3 SSA-500-3 SSN-500G-3
Note: SSN-G is the standard cabinet, the circuit diagram show in table F-7
Ordering
● Users should inform the agent the information such as product type, specification, and load
when ordering, for ensuring what you ordered is proper。
● The SSN/SSA series product is equipped with a bypass contactor terminals. These terminals is
used in above bypass connection mode（for detail see Appendix 2），For the users who wish to
use below bypass connection mode, please say it to the supplier when ordering.
Appendix 2:
SSA serie Structure Size（ Built-in bypass contactor）
Table F-2
Type
Appearance
dimension (mm)
Installation dimension(mm)
Sheet copper
dimension(mm)
weight Kg
Installation
Method
W1 H1 D W2 H2 D1 D2 d W3 W4 H3 D4 d1
SSA-008-3
～
SSA-030-3
205 295 235 180 270 138 70 φ7 63 25 289 3 φ9 10
Wall-suspending
figure F-2
SSA-037-3
～
SSA-045-3
230 380 250 160 355 153 71 Φ7 63 25 371 3 Φ9 14
SSA-055-3
～
SSA-075-3
260 380 266 180 354 173 97 Φ7 75 25 371 3 Φ9 18
SSA-090-3
～
SSA-187-3
265 500 248 220 475 75 42 Φ9 78 35 513 8 φ11 22
