18
3.1.3 Removing
Loosen the knob bolt [1] of powerhead
connections.
Lift the positioning knob [5], and
turn it 90°, either clockwise or
counterclockwise.
Pull out the shaft tube [6].
If the shaft tube is hard to remove, hold
it so that the attachment is parallel to
the pipe of the powerhead, and then
pull it out.
Turn the positioning knob [5] until
it comes to the center and locks in
place. When the positioning knob
[5] is returned to the center, it will be
released downward.
[1]
1
[5]
2
[5]
[6]
3
4
