Niko 05-201 - 4. OPERATION AND CONFIGURATION; Terminal and Button Functions

05-201
48
4. OPERATION AND CONFIGURATION
Connecting terminals and function of the push buttons and LEDs
polarised bus connection B
polarised bus connection B’
conrm/accept
cancel/back
forward/scroll
LEDs
common terminal
RJ12: communication with PC via RS232 or
modem
6 logical inputs
GB
B
X
COM
230V
~50Hz
05-201
LN
B1 B2
B'
1327654
B'1 B'2
