Nikon 1 V1 Reference Manual

16
s
A
Removing Batteries and Memory Cards
After turning the camera off, confirm that
the access lamp is off and open the bat-
tery-chamber/memory card slot cover. To
remove the battery (top), first release it by
pressing the orange battery latch in the
direction shown by the arrow and then
remove the battery by hand. To remove a
memory card (bottom), first press the
card in to eject it (q); the card can then
be removed by hand (w).
D
Memory Cards
• The camera stores pictures on Secure Digital (SD) memory cards
(available separately; 0 165).
• Memory cards may be hot after use. Observe due caution when
removing memory cards from the camera.
• Turn the power off before inserting or removing memory cards.
Do not remove memory cards from the camera, turn the camera
off, or remove or disconnect the power source during formatting
or while data are being recorded, deleted, or copied to a com-
puter. Failure to observe these precautions could result in loss of
data or in damage to the camera or card.
• Do not touch the card terminals with your fingers or metal objects.
• Do not bend, drop, or subject to strong physical shocks.
• Do not apply force to the card casing. Failure to observe this pre-
caution could damage the card.
• Do not expose to water, heat, high levels of humidity, or direct
sunlight.

Nikon 1 V1 Specifications

General

Sensor Type	CMOS
Sensor Size	13.2 x 8.8 mm
Effective Pixels	10.1 million
Screen Resolution	921, 000 dots
Dimensions	113 x 76 x 43.5 mm
Camera Type	Mirrorless
Lens Mount	Nikon 1 mount
Focal Length Multiplier	2.7x
Shutter Speed	30 - 1/16000 sec
Storage Media	SD/SDHC/SDXC
ISO Sensitivity	ISO 100-3200, expandable to 6400
Autofocus System	Hybrid AF with contrast and phase detection
Continuous Shooting Speed	Up to 60 fps
Viewfinder	Electronic (1.44M-dot)
Screen Size	3.0 inches
Video Recording	Full HD 1080p at 30fps
Battery Life	Approx. 350 shots (CIPA)
Weight	294 g (body only)
