Nikon 1 V1 Reference Manual

59
t
In still image mode, the optional SB-N5 flash unit can be used for
additional lighting, to “fill in” (illuminate) shadows and backlit
subjects, or to add catch lights to your subjects’ eyes. In Smart
Photo Selector and Motion Snapshot modes, the flash will not
fire but the capture illuminator will light to illuminate your sub-
ject. The flash does not fire in movie mode or when the Elec-
tronic (Hi) shutter type is selected in still image mode.
Attaching Flash Units
Mount optional flash units on the camera multi accessory port.
1
Remove the multi accessory port cover.
2
Attach the flash unit.
Flash Photography
Remove the cover as shown at right.
Keep the cover in a safe place and
replace it when the port is not in use.
Turn the camera off and mount the
flash unit on the multi accessory port
as described in the manual provided
with the flash unit.

Nikon 1 V1 Specifications

General

Sensor Type	CMOS
Sensor Size	13.2 x 8.8 mm
Effective Pixels	10.1 million
Screen Resolution	921, 000 dots
Dimensions	113 x 76 x 43.5 mm
Camera Type	Mirrorless
Lens Mount	Nikon 1 mount
Focal Length Multiplier	2.7x
Shutter Speed	30 - 1/16000 sec
Storage Media	SD/SDHC/SDXC
ISO Sensitivity	ISO 100-3200, expandable to 6400
Autofocus System	Hybrid AF with contrast and phase detection
Continuous Shooting Speed	Up to 60 fps
Viewfinder	Electronic (1.44M-dot)
Screen Size	3.0 inches
Video Recording	Full HD 1080p at 30fps
Battery Life	Approx. 350 shots (CIPA)
Weight	294 g (body only)
