Nikon 1 V1 Reference Manual

24
z
2
Ready the camera.
Remove the lens cap and hold the
camera securely with both hands,
being careful not to obstruct the lens,
AF-assist illuminator, or microphone.
Rotate the camera as shown at lower
right when taking pictures in “tall”
(portrait) orientation.
Shutter speeds slow when lighting is
poor; use of an optional flash unit
(0 59) or a tripod is recommended.
A
Using a Zoom Lens
Use the zoom ring to zoom in on the subject so that it fills a larger
area of the frame, or zoom out to increase the area visible in the final
photograph (select longer focal lengths on the lens focal length
scale to zoom in, shorter focal lengths to zoom out; if you are using
a lens with a retractable lens barrel button, unlock and extend the
lens by pressing the button and rotating the zoom ring as described
on page 17).
Zoom in
Zoom out
Zoom ring
If you are using an optional lens with a
power drive zoom switch, select T to
zoom in and W to zoom out. The speed
with which the camera zooms in and out
varies with how far you slide the switch.
The zoom position is shown by the zoom
guide in the display.
Zoom guide

Nikon 1 V1 Specifications

General

Sensor Type	CMOS
Sensor Size	13.2 x 8.8 mm
Effective Pixels	10.1 million
Screen Resolution	921, 000 dots
Dimensions	113 x 76 x 43.5 mm
Camera Type	Mirrorless
Lens Mount	Nikon 1 mount
Focal Length Multiplier	2.7x
Shutter Speed	30 - 1/16000 sec
Storage Media	SD/SDHC/SDXC
ISO Sensitivity	ISO 100-3200, expandable to 6400
Autofocus System	Hybrid AF with contrast and phase detection
Continuous Shooting Speed	Up to 60 fps
Viewfinder	Electronic (1.44M-dot)
Screen Size	3.0 inches
Video Recording	Full HD 1080p at 30fps
Battery Life	Approx. 350 shots (CIPA)
Weight	294 g (body only)
