* Camera does not support TA-N100 tripod mounting spacer.
20
1
21
22
10
9
8
5
6
7
11
17
16
19
18
1 O (delete) button................................36
2 $ (display) button......................... 5
3 G (menu) button .......................... 8
4 K (playback) button ............35, 69, 74
5 Fn1 button ............................................12
6 Multi selector......................................... 9
J (OK) button....................................... 9
% (focus mode) ..............................100
E (exposure compensation)
M (flash mode).....................................81
C (continuous shooting/
self-timer)...............................75, 77, 79
7 Memory card slot/connector
cover.....................................................21
8 & (feature) button .............................10
9 Memory card access lamp ................34
10 Power connector cover
for optional power connector
11 Battery-chamber cover ..................... 21
12 Battery-chamber cover
latch......................................................21
13 Grip connector cover .........................29
14 Tripod socket
*
15 Vari-angle monitor.................. 4, 13, 24
16 Speaker
17 A (AE/AF lock) button
18 Power lamp..........................................24
19 Main command dial/
Fn2 button....................... 12, 35, 57, 59
20 HDMI connector
21 USB connector...................................106
22 Memory card slot................................ 21
23 Battery latch......................................... 21
24 Grip connector ....................................29
