Error Messages 10
Total Station DTM-302 Series Instruction Manual 199
Programs 10.6
NO Stn Setup 106.1
You did not perform a station setup or BS check before entering the Programs
function.
C
Warning – Selecting Continue does not resume the last ST record. You
should only use the Continue option if you are sure that the previous ST
coordinates and the current HA orientation are correct. Otherwise, records in
the Programs function may not be correct.
XY&Z coordinate are required 106.2
Three-dimensional coordinates are required in S-Plane function.
Press any key to return to the point input screen. Then enter a three-dimensional
point.
Recording Data 10.7
DATA FULL 107.1
The data storage is full.
Press any key to return to the Basic Measurement Screen (BMS). Then:
DUPLICATE PT 107.2
The input PT you are trying to record already exists in the current job. An existing
coordinate record cannot be overwritten by measured data.
Press any key to return to the point input screen. Change PT.
To ... Press ...
go to the Stn Setup menu [2] or select
Stn Setup
return to the BMS [ESC]
go to the Programs menu [1] or select
Continue
To ... Go to ...
delete unnecessary data
MENU > Data
delete jobs
MENU > Job

Nikon DTM-302 Series Specifications

General

Angle measurement method	Absolute encoder
Angle accuracy	5"
Display	LCD, 20 characters x 2 lines
Weight	4.9 kg (including battery)
Telescope Magnification	30x
Model	DTM-302 Series
Category	Total Station
Accuracy	5"
Operating Temperature	-20°C to +50°C
Data storage	Internal memory
Battery	Rechargeable battery
