Model 50i 55i
Main body Magnification 10-1500X
Optical system CFI60 infinity optical system
Illumination 6V-30W halogen lamp, 100-240V (worldwide voltage) White LED array, AC adapter (100-240V) or optional
lithium battery 7.4V)
Built-in ND8 Filter Built-in LA60 Color balance filter
Preset switch
Built-in power supply
Focusing Manual coaxial coarse/fine focusing
Focusing stroke : 30mm
Coarse : 13.8mm/rotation, Fine : 0.1mm/rotation
Minimum reading : 1um
Refocusing function with stopper, Coarse motion torque adjustable
Eyepiece Tube (Light distribution) Y-TB Binocular Tube F.O.V. 22
Y-TF Trinocular Tube F UW F.O.V. 22/25mm (Eyepiece/Port : 100/0, 0/100)
Y-TT Trinocular Tube T UW F.O.V. 22/25mm (Eyepiece/Port : 100/0, 20/80, 0/100)
C-TE Ergonomic Binocular Tube F.O.V. 22mm inclination angle : 10-30 tube extension up to 40mm
(*when C-TEP DSC port is attached: Eyepiece/Port 100/0, 50/50)
Eyepiece Lens (F.O.V.) 10X (22mm), 10X M photomask (25mm), 12.5X (16mm), 15X (14.5),
UW10X (25mm), UW 10X M photomask (25mm)
Nosepiece C-N Sextuple Nosepiece
J-CY Cytodiagnostic Unit (Motorized changeover between 10X/40X with hand switch, stamtype marking)
(Automatic intensity adjustment is available when used with 55i.)
Stage C-SR Rectangular Mechanical Stage
Cross travel 78(X) x 54(Y) mm, with calibrations, Stay-in -position stage handle height and torque adjustable
Super-hard Alumite coated surface, rackless
C-HC1/HL2 Specimen Holders for 1 slide/2 slides
Condenser C-C Abbe, C-C Achromat, Achromat Swing-out 2-100X, C-C Achromat Swing-out 1-100X,
C-C Low Power, C-C Achromat/Aplanat, LWD Achromat
C-C Phase Contrast, Darkfield (Dry/Oil) —
Power Consumption (max.) 100-230V, 0.9A/48W 100-230V, 0.2A/6W
Weight (approx.) 13.8 kg (standard binocular set)
MAIN ACCESSORIES
J-FL Epi-Fluorescence Attachment 4-position Filter Turret (switching between two positions only or locking mechanism available), Manual Epi-
Shutter
Digital Sight series Digital Camera Various combination selectable from camera head DS-5M (standard) /5Mc(cooled) and Control Unit L1
(stand-alone)/U1(PC-use)
Others C-ER, Eyelevel Riser, Y-IDP Double Port, Y-IDT Drawing Tube, Y-IM Magnification Module, CCTV Adapters
Teaching heads, Simple Polarizing Set —
Specifications
Dimensional diagram
NIKON INSTECH CO., LTD.
Parale Mitsui Bldg.,8, Higashida-cho, Kawasaki-ku,
Kawasaki, Kanagawa 210-0005, Japan
phone: +81-44-223-2167 fax: +81-44-223-2182
www.nikon-instruments.jp/eng/
NIKON INSTRUMENTS (SHANGHAI) CO., LTD.
CHINA phone: +86-21-5058-5055 fax: +86-21-5058-5060
(Beijing office)
CHINA phone: +86-10-5869-2255 fax: +86-10-5869-2277
NIKON SINGAPORE PTE LTD
SINGAPORE phone: +65-6559-3618 fax: +65-6559-3668
NIKON MALAYSIA SDN. BHD.
MALAYSIA phone: +60-3-78763887 fax: +60-3-78763387
