Internal display
1 Battery condition
2 Laser irradiation mark: Displayed when the laser is being emitted. Do
not look into the product from the objective lens side while this is
displayed.
3 Horizontal distance mode
4 Target mark
5 Unit of measure (M: meter/Y: yard)
6 Distance
* The internal display of this product is enlarged by the eyepieces. Although you
may see dust that has entered, it does not effect the accuracy of measurement.
3
4
5
Preparation
Type of battery
3V CR2 lithium battery x1
Inserting/replacing the battery
1. Open the battery chamber cover.
• Rotate the battery chamber cover counterclockwise with an object such as a coin to open it.
2. Insert the battery.
• To replace the battery, take out the old battery before inserting a new one.
• Follow the battery insertion mark inside the battery chamber to insert the + and - ends of the battery
in the correct orientation (insert so that the - end faces up).
3. Attach the battery chamber cover.
• Rotate the battery chamber cover clockwise with an object such as a coin and secure it firmly.
• When attaching the battery chamber cover, securely screw it all the way and check that it is secured.
* The battery chamber cover may be difficult to rotate because this product uses a rubber seal to maintain its waterproof
capabilities.
