Adjusting the focus of the internal display and diopter difference
1. Press the PWR button to turn on the power.
• The internal display is displayed.
2. Look in only with your right eye, rotate the internal display diopter adjustment ring, and adjust the focus
of the internal display.
3. Designate a target.
• You can correctly focus by adjusting each eye with respect to the same target.
4. Look in only with your right eye, rotate the focusing ring, and adjust the focus of your right eye.
5. Look in only with your left eye, rotate the diopter adjustment ring, and adjust the focus of your left eye.
• Correct the difference (diopter difference) in vision between the left and right.
6. Look in with both eyes and check if the focus is correct.
7. When you view a different subject, adjust the focusing ring until you obtain a sharp image.
Mode settings
You can change the settings of each mode. The details of each mode and the settings at the time of purchase
(factory default settings) are explained below. If you do not need to change the settings, proceed to
“Measurement” (page 20).
Mode Details Factory default setting
Internal display
luminance (IL)
Adjust the brightness of the internal display. IL1 is the
darkest, while IL4 is the brightest.
IL4
Distance display
unit (F1)
Select yards (Y) or meters (M) for the units of the
measurement results.
Yard (Y)
Measurement
display mode (F2)
Select horizontal distance (
) or actual distance (
hidden) for the display of the measurement results.
Horizontal distance ( )
