Foundation
ATTENTION
Place the AIR unit on a stable base, ideally a cast foundation.
ATTENTION
The illustration above shows an example of an AIR9 outdoor unit. See dimensional sketch for details on AIR9 and AIR9 +.
Soakaway Electrical conduit min. 50mm
Drain to condensate
Foundation
Adjustable feet
