nilan CTS 602 Installation And User Guide

All rights reserved Side 12 af 16
HotWater.TempSet_
T11
1700
100
°C
Top temperature setpoint
(electric)
VGU-VP-Compact
HotWater.TempSet_
T12
1701
100
°C
Bottom temperature setpoint
(compressor)
VGU-VP-Compact
CentralHeat.HeatExt
ern
1800
100
°C
External heating offset from
room temperature setpoint
VPL-VP-Compact-
VPcCoB-
AirQual.RH_VentLo
1910
Step
Humidity low winter step select
All plants
AirQual.RH_VentHi
1911
Step
Humidity high step select
All plants
AirQual.RH_LimLo
1912
100
%
Humidity limit for low ventilation
AirQual.RH_TimeOut
1913
min
Humidity max. time on high
ventilation
All plants
AirQual.CO2_VentHi
1920
Step
CO2 high step select
All plants
AirQual.CO2_LimLo
1921
ppm
CO2 limit for normal ventilation
All plants
AirQual.CO2_LimHi
1922
ppm
CO2 limit for high ventilation
All plants
Display.KeyCode
2000
User panel keypress
Repeated if not cleared within
400 ms
Combined value with one bit for
each key
0x01 : ESCAPE
0x02 : UP
0x04 : DOWN
0x08 : ENTER
0x10 : OFF
0x20 : ON
All plants
