nilan CTS 602 Installation And User Guide

All rights reserved Side 6 af 16
Control.State
1002
Actual control state
0 : Off
1 : Shift
2 : Stop
3 : Start
4 : Standby
5 : Ventilation stop
6 : Ventilation
7 : Heating
8 : Cooling
9 : Hot water
10 : Legionella
11 : Cooling + hot water
12 : Central heating
13 : Defrost
14 : Frost secure
15 : Service
16 : Alarm
17: Heating + hot water
All
Control.SecInState
1003
Sec
Actual time in state
All
AirFlow.VentSet
1100
Step
Actual ventilation step set point
0 : Off
1..4 : Step number
All
AirFlow.InletAct
1101
Step
Actual ventilation step set point
0 : Off
1..4 : Step number
All
AirFlow.ExhaustAct
1102
Step
Actual ventilation step set point
0 : Off
1..4 : Step number
All
AirFlow.SinceFiltDay
1103
Days
Days since last air filter
change alarm
One day is measured as 24
hours of active running time
All
AirFlow.ToFiltDay
1104
Days
Days to next air filter change
alarm
One day is measured as 24
hours of active running time
All
AirTemp.IsSummer
1200
Summer state
0 : Off
1 : On
All
AirTemp.TempInletS
et
1201
100
°C
Inlet temperature request (T7
setpoint)
All
AirTemp.TempContro
l
1202
100
°C
Actual value for controlled
temperature
All
AirTemp.TempRoom
1203
100
°C
Actual room temperature (T15
or T10)
All
AirTemp.EffPct
1204
100
%
Passive heat exchanger
efficiency
Compact-Comfort-
Comforti
AirTemp.CapSet
1205
100
%
Requested capacity
All plants
AirTemp.CapAct
1206
100
%
Actual capacity
All plants
