nilan CTS 602 Installation And User Guide

All rights reserved Side 5 af 16
Input.T9_Heater
209
100
°C
Heating surface temperature
VPL-VPM-Comfort-
Comforti
Input.T10_Extern
210
100
°C
External room temperature
All plants
Input.T11_Top
211
100
°C
Hot water top temperature
VGU-VP-Compact
Input.T12_Bottom
212
100
°C
Hot water bottom temperature
VGU-VP-Compact
Input.T13_Return
213
100
°C
EK return temperature
VGU-VP
Input.T14_Supply
214
100
°C
EK supply temperature
VGU-VP
Input.T15_Room
215
100
°C
User panel room temperature
All plants
Input.T16
216
100
°C
AUX temperature (sacrificial
anode)
VGU-VP-Compact
Input.T17
217
100
°C
Preheater or earth tube air
intake temperature
--
218..220
(reserved)
Input.RH
221
100
%
Humidity
All plants
Input.CO2
222
ppm
Carbon dioxide
All plants
Alarm.Status
400
Alarm state bit mask
0x80 : Active alarm(s) present
0x03 : Nb. of alarms listed
All
Alarm.List_1_ID
401
Alarm 1 – Code
0x80 : (reserved future use)
0x7F : Display code 1..99
All
Alarm.List_1_Date
402
Alarm 1 – Date
Bit word packed in DOS date
format. Year 0 = 1980
15 8 7 0
HHHHHMMM MMMSSSSS
All
Alarm.List_1_Time
403
Alarm 1 – Time
Bit word packed in DOS time
format. Seconds are in scale 2
(0..29=0..58 seconds)
15 8 7 0
HHHHHMMM MMMSSSSS
All
Alarm.List_2_ID
404
Alarm 2 - Code
All
Alarm.List_2_Date
405
Alarm 2 - Date
All
Alarm.List_2_Time
406
Alarm 2 - Time
All
Alarm.List_3_ID
407
Alarm 3 - Code
All
Alarm.List_3_Date
408
Alarm 3 - Date
All
Alarm.List_3_Time
409
Alarm 3 - Time
All
Control.RunAct
1000
Actual on/off state
0 : Off
1 : On
All
Control.ModeAct
1001
Actual operation mode
0 : Off
1 : Heat
2 : Cool
3 : Auto
4 : Service
All
