12
Set-up
Mounting
Positioning of the ventilation unit
The unit makes little noise and it produces only weak vibrations, but you should still take into account potential vibrations that can
spread from the unit to individual building components. In order to separate the unit from its underlying surface, it is therefore
recommended that you fit vibration absorbers under the unit. There should be approx. 10 mm distance to other building components
and to permanent fixtures.
Top unit
Mounting the ventilation unit
ATTENTON
When positioning the unit, you should always consider future service and maintenance.
It must be easy to replace filters, and it must be possible to remove, for instance, the exchanger, and to replace fans or
other components.
ATTENTON
A free space is recommended in front of the ventilation unit of at least 60 cm.
It must be easy to replace filters and e.g. it must be possible to remove the exchanger, replace the fan or other
components.
ATTENTON
The unit must be level to enable proper drainage from the condensate tray.
ATTENTION
If you fit flashings above the unit, there must be
enough space to remove these easily.
The unit is equipped with two mounting brackets with holes for
wall mounting at the top back of the unit.
