nilan CTS700-TOUCH - Connections List, External Unit

46
Connections list, external unit
1. Supply flow to internal unit (hot), fitted with 1" flexible hose
2. Return from internal unit (cold), fitted with 1" flexible hose
3. Condensate drain
4. Hole for connections
ATTENTION
The illustration above shows an example of an AIR outdoor unit. See dimensional sketch for details on AIR9 and AIR9 +.
TRUE
FALSE
