nilan VPL 25 - Heating surface, electrical (retrofitting)

This document may be subject to change Side 10 of 23
Heating surface, electrical (retrofitting)
Electrical heating surface should be installed in the ducting (Ø160/Ø200). When retrofitting an elec-
trical heating surface it should be activated in the 600 control panel as described on page 15.

Power supply must be installed by an authorized electrician.
See electrical chart for the ventilation unit and electrical chart for LMC200 PCB A - H.
