D
OORBELL
I
NTERFACE
15
SPECIFICA
TIONS
Audio
• Chime: 100Hz ~ 3kHz, +/- 3dB
• Audio Pass Through: 10Hz ~ 50kHz, +/- 0.5dB
T
rigger Inputs
• V
oltage T
rigger Input: 3V-30V AC/DC
• Contact Closure Inputs: < 100 ohms
Power Supply
• INPUT
: 100-240V AC 50-60Hz 40W
• OUTPUT
: 1
2V DC 1.2 A
Unit Dimensions
• 7-7/8" wide x 1-1/8" high x 4-1/8" deep
NOTES
D
OORBELL
I
NTERFACE
14
7
Table of Contents
Introduction
2
Features and Benefits
2
Table of Contents
2
Parts Guide
3
Description
3
Operation Overview
4
Installation Considerations
4
Installation
4
Mounting the DBI-1
4
Connecting the DBI-1
4
Installation Settings
6
Contact Closure Triggers
6
30V Voltage Triggers
6
Chime and Audio Level Adjustments
6
Setting the Tone/Delay
6
Recommended Tone/Delay Settings
6
Identifying the Version of a Niles Multizone System
6
Chime Selection
7
Recording a Custom Chime
7
Recording an Active Audio Signal
7
Recording a Paused Audio Signal
7
Specifications
8
