S TEREO A MPLIFIER/ AUTOMATED S WITCHER
SPECIFICATIONS
Power: 50 watts per channel RMS into
4/8 ohms.
S/N Ratio: >94dB
THD: .05% at rated power.
Mounting: Horizontal or vertical mount-
ing. Keyholes in back panel for vertical
mount.
Connectors:
12V Trigger IN/OUT: 3.5mm mini
phone jack.
LINE IN: Gold plated RCA
SPEAKER (All): Screwless 4 pin plug-in.
AC IN: IEC type three prong.
Current Sensing Outlet
Wire requirements: 14-16 gauge two-con-
ductor speaker wire for all speaker level
connections.
Trigger voltage: IN: 3-30VAC/DC
Trigger voltage OUT: 12VDC/200mA
AC requirement: 120V – 60Hz
Input sensitivity: 500mV @ full output
Dimensions: 2-1/4"H x 8"W x 7-1/2"D
Weight: 3-1/2" lbs
CONTENTS
TVA50 1
IEC three prong AC power cord 1
Screwless connectors 4
Self adhesive rubber feet 4
