Niles TVA50 - To Current Sensing Outlet; TV Current Sense with One Speaker Pair

7
S TEREO A MPLIFIER/ AUTOMATED S WITCHER
Speaker (A)
To Speaker
(A) Input
Right
Left
Whole House Receiver
TV - Local Room
Right/Left
TV Variable
Line Out
TV - Power
Cord
To Current Sensing Outlet
TVA-50
To Unswitched
Outlet
Speaker
(A) Out
Figure 3
TV current sense with one speaker pair
Right
Left
