ZR-6 MULTIZONE SYSTEM DESIGN GUIDE
Installation Bene ts
The ZR-6 is a scalable MultiZone
Receiver with native iPod integration and
a desirable feature set that includes a
touchscreen, a water-resistant keypad
option with metadata, preamp outputs,
4-ohm stable digital amplifi er, and paging
ability. Additionally, high defi nition video
distribution can be easily added on to the
ZR-6 by using the VS-6 High Defi nition
Component Video Switcher. Most
importantly, the ZR-6 is able to control
and power manage all sources connected
to it through built-in IR learning and power
sync technology.
Customer Bene ts
The ZR-6 offers your customer a cost-
effective MultiZone receiver that allows
One Touch to Entertainment from an
easy-to-learn keypad or touchscreen.
They get complete control of their iPod
through a recognizable user interface from
any location in the house.
CRITICAL KNOWLEDGE
When installing the Solo-6IR or Solo-
6MD into a “wet” environment, the
unit must have a complete “positive”
seal with the mounting surface. This
is achieved by using silicone caulking
on the gap around the plate and the
Decora
®
style insert and then installing
the wall plate to complete the seal.
It is recommended that additional
installation time be applied to these
keypad locations. It may be necessary
to disable the IR sensor if the keypad is
exposed to direct sunlight. The TS-Pro
touchscreen should not be mounted in
a wet environment.
Whenever an iPod is connected to a
ZR-6, the Input 2 RCA jacks become
an iPod cascade output. These are
used to route the iPod audio signal to
any additional Slave chassis.
The ZR-6 can ONLY be used with the
SmartDock2 and ES2. Please check
the iWARE
®
2 iPod Compatibility Chart
in the Additional Documents section at:
www.nilesaudio.com/techsupport/
INSTALLATION REQUIREMENTS
All CAT-5 wiring must be terminated
using the T568A wiring convention.
The following steps are required to
confi gure a ZR-6 for operation:
1. Set tuner presets
2. Confi gure unit through front panel
display
3. Teach IR codes into chassis
4. Create sequences for all Master
keys (IR codes for VS-6 are
preloaded into the ZR-6)
5. Set bass, treble, variable loudness,
and IR sensor on/off in each zone
from keypad
6. Program all remotes
SEE NEXT PAGE
FOR DIAGRAM
CABLE SCHEDULE
Source connections Audio Room connections (needed for each area that accesses the audio sources)
QTY CABLE SIGNAL FROM TO QTY CABLE SIGNAL FROM TO
1
Stereo RCA Audio ZR-6 Source 2 Input AVDA-3
1
#1 Input
1
Speaker Audio ZR-6 Zone Amplifier Output Speakers
1
Stereo RCA Audio
Satellite Receiver
Audio Output
AVDA-3 #2 Input
1
CAT-5 Data ZR-6 Keypad Port
Keypad or
Touchscreen
1
Stereo RCA Audio Cable Box Audio Output AVDA-3 #3 Input
Systems Integration Amplifier Connections
1
Stereo RCA Audio CD Audio Output AVDA-3 #4 Input
1
Stereo RCA Audio
Slave ZR-6 Zone 6
Preamp Output
SI-275 Audio Input
1
Stereo RCA Audio AVDA-3 #1 Output Slave ZR-6 Source 2 Input
1
3.5mm 12V DC
Slave ZR-6 Zone 6
12V DC Trigger Output
SI-275 Trigger Input
1
Stereo RCA Audio AVDA-3 #2 Output Master ZR-6 Source 3 Input
1
Speaker Audio SI-275 Speaker Output Speakers
1
Stereo RCA Audio AVDA-3 #2 Output Slave ZR-6 Source 3 Input
ZR-6 Slave Control Connections
1
Stereo RCA Audio AVDA-3 #3 Output Master ZR-6 Source 4 Input
1
CAT-5 Data Master ZR-6 Expansion Input
Slave ZR-6
Expansion Output
1
Stereo RCA Audio AVDA-3 #3 Output Slave ZR-6 Source 4 Input
1
Stereo RCA Audio AVDA-3 #4 Output Master ZR-6 Source 5 Input
1
Stereo RCA Audio AVDA-3 #4 Output Slave ZR-6 Source 5 Input
1
Flasher Infrared Master ZR-6 Flasher #3 Satellite Receiver
1
Flasher Infrared Master ZR-6 Flasher #4 Cable Box
1
Flasher Infrared Master ZR-6 Flasher #5 CD Player
1
iPod
(supplied)
Audio +
Data
Master ZR-6 iPod Input iPod
1
AVDA-3 only necessary for source 2 output if 3rd chassis is used
To Next Page
