ZR-6 MULTIZONE SYSTEM DESIGN GUIDE
For connection
of power supply
Connects with CAT-5
cable to the  rst keypad
(ZR-4 and ZR-6)
Connects with CAT-5
cable to the second
keypad (ZR-4 and ZR-6)
Connects with CAT-5
cable to the third
keypad (ZR-6 ONLY)
Connects to a ZR-4 or ZR-6
MultiZone Receiver keypad
port with CAT-5 cable
Indicates ZR-KE
is operational
Features
■ With the ZR-4, allows you to add an additional keypad in any of the ZR-4 zones
■ With the ZR-6, allows you to add up to two additional Solo-6 IR, Solo-6 MD, and/or TS-Pro keypads in any of the ZR-6 zones
■ Ideal for enhancing system control in larger living rooms, dining rooms, dens and outdoor areas
■ Single input and three outputs (two outputs can be used with the ZR-4, three outputs with the ZR-6)
Specifications
■ Dimensions: 4-3/4" wide x 1-1/4" high x 2" deep (12cm wide x 3.2cm high x 5.1cm deep)

Niles ZR-6 Specifications

General

Brand	Niles
Model	ZR-6
Category	Receiver
Language	English
