Niles ZR-6 Design Guide

THE FIRST NAME IN CUSTOM INSTALLATION
®
39
ZR-6 MULTIZONE SYSTEM DESIGN GUIDE
WHAT DOES THIS APPLICATION DO?
This application demonstrates how to remotely locate a SmartDock2 and connect it to both a PC and the ZR-6 MultiZone Receiver.
DO THIS FIRST
Review the compatible iPod models list
CRITICAL KNOWLEDGE
1) The SmartDock2 and ES2 are not
compatible with any fi rst generation
SmartDocks or ES1s!
2) The 30-pin iPod cable supplied with
the ZR-6 MultiZone Receiver connects
the ZR-6 (or ES2 input wall plate)
directly to an iPod. The 30-pin cable
supplied with the SmartDock2 and
ES2 connects the SmartDock2 or ES2
output wall plate to the ZR-6, or the
ES2 input wall plate to a SmartDock2.
Please note these two 30-pin cables
are not the same and cannot be
interchanged.
3) Although CAT-6 offers higher
communication speeds, its increased
twists per inch may reduce the
maximum distance between the two
wall plates. CAT-5 is recommended for
wire runs greater than 75 ft.
4) In a multi-chassis ZR-6 MultiZone
Receiver system, there can be only one
iPod connected to the system.
Key Considerations
The SmartDock2 connects an iPod to
the ZR-6 MultiZone Receiver and enables
you to sync with iTunes on a computer.
The ES-2 extension kit allows you to
conveniently integrate an iPod to the ZR-6
from anywhere in the home.
Customer Bene ts
Integration of an iPod into a ZR-6 MultiZone
Receiver becomes seamless and elegant.
Installation Bene ts
The ES2 and SmartDock2 combination
allows the installer to locate the iPod in
any location that the customer desires,
while still being accessible to the ZR-6
MultiZone system.
APPLICATION: ADDING AN iPod
®
USING THE
SMARTDOCK
®
2 AND ES2
CABLE SCHEDULE
SmartDock2 Connections
QTY CABLE SIGNAL FROM TO
1 30-pin Data SmartDock2 ZR-6 30-pin
1 USB Data SmartDock2 iTunes Computer
ES2 Connections
QTY CABLE SIGNAL FROM TO
2 CAT-5 Data ES2 Input Plate ES2 Output Plate
1 30-pin Data SmartDock2 ES2 Input Plate
1 30-pin Data ES2 Output Plate ZR-6 30-pin
1 12V DC Power AC Outlet ES2 Input Plate
INSTALLATION REQUIREMENTS
The ES2 requires two (2) CAT-5 cables
between the two wall plates. The
input wall plate (the iPod end) must be
powered by the included power supply
that can be connected to the front or
rear of the input wall plate.
