Disposal of the ma chine -
Dispose of the machine in com pli ance with the current laws
in force.
Correct Disposal of This Product (Waste Electrical & -
Electronic Equipment) (Applicable in the European
Union and other European countries with separate
collection systems)
This marking (pos. N - fi g. 1) shown on the product or its
literature, indicates that it should not be disposed with other
household wastes at the end of its working life. To prevent
possible harm to the environment or human health from
uncontrolled waste disposal, please separate this from other
types of wastes and recycle it responsibly to promote the
sustainable reuse of material resources. Household users
should contact either the retailer where they purchased this
product, or their local government offi ce, for details of where
and how they can take this item for environmentally safe
recycling. Business users should contact their supplier and
check the terms and conditions of the purchase contract.
This product should not be mixed with other commercial
wastes for disposal.
Wiring diagrams -
See fi g. 18.
Wiring diagram key
Abbrev. Component Code
J1 Antidisturb fi lter 8 39533
P1 Pressure switch 8 40403
S1 - S2 - S3 Motors switches 8 39525
H1
Filter blocked warning
light
8 39530
H2
Presence tension warn-
ing light
8 39526
XC1 Plug 16 A 8 39527
Recommended spares -
The following is a list of spare parts that should be kept ready to hand in order to speed up maintenance work. (fi g. 19).
Recommended spare parts list (fi g. 19)
Pos. Description Model Dim. Code number
1 Star-shaped fi lter “L”
127 - 127 L
137 - 137 L
Ø 460 17080
2 Star-shaped fi lter “M”
127 M
137 M
Ø 460 17245
3 Filter ring
127 - 127 L, M, H
137 - 137 L, M, H
Ø 460 15003
4 1000 W single-phase motor 54002
5 Filter ring seal
127 - 127 L, M, H
137 - 137 L, M, H
Ø 460 17026
6 Filter clamp
127 - 127 L, M, H
137 - 137 L, M, H
Ø 460 18079
7 Absolute fi lter “H”
127 H
137 H
Ø 410 17455
8 Box / Cover
127 L - M - H
137 L - M - H
Ø 460 8 30202 + 8 31365
