General Information
11
Service Manual – SC400
Machine Nomenclature (Continues)
FRONT OF
MACHINE
BACK OF
MACHINE
PANEL
12V 12V
PANEL
Recovery tank cover (open)
Brush
Machine forward
speed adjusting handwheel
Machine straight forward
movement adjusting handwheel
Battery
connection
diagram
Batteries
Brush motor
Vacuum system motor
Detergent removable filler hose
Vacuum grid with automatic shut-off float
Solution tank filler neck
Recovery tank compartment
Front brush support
Recovery tank cover gasket
Lifted
squeegee
Brush rotation direction
Pad
Pad-holder
P200003
To Next Page
