General Information
12
Service Manual – SC400
Handlebar with Control Panel
Handlebar
Program: brush - solution
flow activation
Program selection knob / rotary switch
Program: brush - vacuum system -
solution flow activation
Machine start-up enabling
push-button(*)
Program: vacuum
system activation
Machine switching off “0”
Solution flow push-button
Brush lever(*)
(*) The brush levers operate only after pushing the machine start-up enabling push-button
Handlebar inclination
adjusting lever
Brush lever(*)
LED indicators for:
- solution quantity
- battery charge
P200044
