9Service Manual – SC901 03 - General Information
Lifting or Transporting the Machine
CAUTION: Never work under a machine without safety stands or blocks to support the machine.
− Drain the recovery and solution tanks to prevent sloshing water from unbalancing the
machine.
− Lift only from the subframe of the machine, as shown below.
− Secure the machine to the transport using the tie down points shown below.
The actual procedure for transporting the machine will vary depending on the mode of transport. Follow
these general guidelines as applicable to the situation.
• Remove the squeegee from the machine. This is required to access the rear hold down points and also
protects the squeegee during loading, unloading, and transport.
• If transport will occur below freezing temperatures, place a small amount of environmentally friendly
antifreeze in the recovery tank, solution tank, and solution lines.
• Make sure all doors, panels, and covers are secure.
• Secure the machine to the transport using both front and both rear tie down points.
Tie Downs &
Rear Lift Points
Tie Downs
