FORM NO. 56043088 / Advenger
™
/ BR 600S, 650S, 700S, 800S - 11
FUNCTIONAL DESCRIPTION OF CONTROL BUTTONS:
The controls on the Advenger were designed with one touch operation in mind. For single pass scrubbing the user can simply depress one switch
and all systems on the machine will be ready to go.
For most single-pass scrubbing operations, the operator should only need to use the top three switches on the control panel. These are the Scrub
System Off, Scrub Pressure Decrease, and Scrub Pressure Increase switches.
Scrub Off Switch (B) - Pressing this switch when the unit is in a scrub mode will cause the following to occur:
• The scrub brushes will turn off and the scrub deck will raise to the up position
• The solution fl ow will be stopped
• The fi rst time that this switch is pressed, the vacuum/squeegee system will NOT be turned off. This is so that any remaining water may be picked up without
having to turn the vacuum back on. If this switch is pressed a second time (pressed after the scrub system has been turned off) the squeegee will raise and
the vacuum will shut of after a 10 second delay.
• The travel speed limit will return to the transport speed setting.
Scrub Pressure Decrease Switch (D) – If the scrub system is off, pressing this switch will cause the following to occur:
• The scrub system will be enabled with the scrub pressure set to the last used setting and the scrub deck will be lowered
• The vacuum system will be enabled and the squeegee will be lowered
• The solution system will be enabled
• The travel speed will be limited to the scrub speed setting
• As soon as the throttle is moved from the neutral position the scrub brushes will start turning and the vacuum will turn on. If the direction is forward the solution
fl ow will start. If the direction is reverse, the squeegee will raise and the solution fl ow will be stopped.
If the scrub system is already enabled when this switch is pressed, the scrub pressure will decrease. If the switch is held, the pressure will decrement until the
minimum setting of 1 is reached.
Scrub Pressure Increase Switch (F) – If the scrub system is off, pressing this switch will cause the following to occur:
• The scrub system will be enabled with the scrub pressure set to the last used setting and the scrub deck will be lowered
• The vacuum system will be enabled and the squeegee will be lowered
• The solution system will be enabled
• The travel speed will be limited to the scrub speed setting
• As soon as the throttle is moved from the neutral position the scrub brushes will start turning and the vacuum will turn on. If the direction is forward the solution
fl ow will start. If the direction is reverse, the squeegee will raise and the solution fl ow will be stopped.
If the scrub system is already enabled when this switch is pressed, the scrub pressure will increase. If the switch is held, the pressure will increment until the
maximum programmed limit is reached (default = 9).
Wand Switch (I) – This switch is used when an external scrub wand is used. Pressing this switch will turn the vacuum on continuously without
regard to the throttle position. It will also enable the optional solution pump. If the scrub system was on it will be turned off. This includes turning off
the scrub brushes and raising the scrub deck, turning the solution fl ow off (to the scrub deck) and raising the squeegee. NOTE: automatic shutoff
of the vacuum motor when the recovery tank is full is disabled when the wand is enabled. The fl oat in the recovery tank will still prevent water from
entering the vacuum motor, but the motor will not shut off.
Key Switch (J) – Main power switch
Speed Select Switch (L) – This switch will allow the operator to select the transport speed limit while the scrub system is enabled thereby allowing
scrubbing at a higher rate of speed. This option can be disabled if desired. See the programming section for details.
The transport and scrub speed limits can be programmed using a Curtis handheld programmer. Refer to the Curtis Speed Control manual section
for details.
Horn Switch (N) – This switch will sound the horn as long as the switch is held.
The horn also functions as an automatic back-up alarm when the throttle is moved to the reverse position. The volume of the back-up alarm
is programmable. It can also be programmed to provide an annunciation feature that will sound whenever the machine is in motion. See the
programming section for details.
Vacuum Switch (O) – This switch is used to turn the vacuum system on or off. When the vacuum is on the squeegee will lower (unless the machine
is in reverse) and when the vacuum is off the squeegee will raise. Pressing this switch will alternate between on and off. The vacuum will only turn
on when the throttle is moved from the neutral position. It will remain on for 10 seconds after the throttle returns to neutral.
The vacuum also has an automatic shutoff feature that will turn the vacuum and scrub systems off if the recovery tank becomes full. This feature
can be disabled if desired. See the programming section for details.
Solution Switch (R) – This switch is used to turn the solution system on or off. Pressing this switch when the scrub system has been activated will
alternate between on and off. The solution fl ow will only turn on when the throttle is moved from the neutral position in the forward direction. The
solution fl ow will turn off if the throttle returns to neutral or is moved to reverse.
Pressing this switch when the scrub system is off will momentarily turn the solution fl ow on to allow pre-wetting of the scrub brushes.
KNOW YOUR MACHINE
