ELECTRICAL SYSTEM
FORM NO. 56043088 / Advenger
/ BR 600S, 650S, 700S, 800S - 61
Fixed Pressure Mode
1 Turn the main power key switch to the off position.
2 Press and hold the scrub pressure decrease switch.
3 While holding the pressure decrease switch turn the main power key switch to the on position.
4 Continue to hold the pressure decrease switch until the scrub pressure decrease indicator is green.
5 Release the pressure decrease switch.
6 Pressing and releasing the scrub pressure decrease switch will now select between “0” for no adjustable pressures ( xed pressure mode), “1”
for one adjustable pressure (pressure increase/decrease mode) or “2” for two adjustable pressures (light/heavy scrub pressure mode). Set the
mode to “0”.
7 Press the scrub system off switch to save this setting.
8 The status display will now show a number from 1 to 5. This represents the scrub pressure that the operator will be able to select using the light
scrub pressure select switch. Use the pressure decrease switch to set the desired pressure.
9 Press the scrub system off switch to save this setting.
10 The status display will now show a number from (1 + the setting from step 8) to 9. This represents the scrub pressure that the operator will be
able to select using the heavy scrub pressure select switch. The scrub pressure increase indicator will now be illuminated. Use the pressure
increase switch to set the desired pressure.
11 Press the scrub system off switch to save this setting.
12 The status display will now show “d” to indicate that the procedure is done.
13 The new setting will be saved and will remain in effect until it is changed again.
Light / Heavy Scrub Mode
1 Turn the main power key switch to the off position.
2 Press and hold the scrub pressure decrease switch.
3 While holding the pressure decrease switch turn the main power key switch to the on position.
4 Continue to hold the pressure decrease switch until the scrub pressure decrease indicator is green.
5 Release the pressure decrease switch.
6 Pressing and releasing the scrub pressure decrease switch will now select between “0” for no adjustable pressures ( xed pressure mode), “1”
for one adjustable pressure (pressure increase/decrease mode) or “2” for two adjustable pressures (light/heavy scrub pressure mode). Set the
mode to “2”.
7 Press the scrub system off switch to save this setting.
8 The status display will now show a number from 1 to 5. This represents the maximum scrub pressure that the operator will be able to select
using the light scrub pressure select switch. Use the pressure decrease switch to set the desired pressure.
9 Press the scrub system off switch to save this setting.
10 The status display will now show a number from (1 + the setting from step 8) to 9. This represents the maximum scrub pressure that the operator
will be able to select using the heavy scrub pressure select switch. The scrub pressure increase indicator will now be illuminated. Use the
pressure increase switch to set the desired pressure.
11 Press the scrub system off switch to save this setting.
12 The status display will now show “d” to indicate that the procedure is done.
13 The new setting will be saved and will remain in effect until it is changed again.
SPECIAL PROGRAM OPTIONS (CONTINUED)
* Values given are approximate.
2400D / BR600S
(Disc) 1 HP
123456789
15.0 16.4 17.8 19.1 20.5 21.9 23.3 24.6 26.0
15.0 17.0 19.0 21.0 23.0 25.0 27.0 29.0 31.0
2600D / BR650S
(Disc) 1-1/4 HP
2810D / BR700S
3210D / BR800S
(Disc) 1-1/2 HP
2400C / BR600CS
2600C / BR650CS
2810C / BR700CS
3210C / BR800CS
(All Cyl.) (2) 3/4 HP
PA#
SCRUB PRESSURE (PA#) & CURRENT LOAD (AM PS) SPECIFICATIONS (TABLE 2)
15.0 17.5 20.0 22.5 25.0 27.5 30.0 32.5 35.0
15.0 17.5 20.0 22.5 25.0 27.5 30.0 32.5 35.0
