D - BATTERY CONDITION INDICATOR OPERATION
To operate, the Brush Switch (13) or the Vac Switch (14) must be turned on to
activate the Battery Condition Indicator (19) to determine the charge condition
of the battery pack.
Listed below is the explanation of the Battery Condition Indicator (19) light
functions:
1 Flashing Red Light: Condition of battery 95% to 99% discharged.
2 Constant Red Light: 100% discharged.*
*NOTE: When the indicator glows steady RED, the operator will have 2
minutes of run time left (for batteries in good condition). The brush motor will
automatically shut off and the vac motor will continue to run for 10 minutes to
pick up any solution left on the floor.
Additional Note: If at any time during machine operation the battery system
voltage drops below 19 volts, the brush and vac motors will immediately shut
off. The red light will also glow steady to indicate a low voltage fault condition.
Check condition of batteries and recharge them.
If an overload occurs, determine and correct the cause of the overload. The
machine has an internal electronic circuit breaker built into the control board.
To reset the electronic circuit breaker, turn the switch for the affected device
off and then back on.
TROUBLESHOOTING
POOR WATER PICKUP
1 Recovery tank full, float shut-off closed
2 Blocked vacuum system (squeegee hose and float cage)
3 Disconnected or damaged vacuum hoses
4 Blades worn or damaged
5 Recovery tank cover not seated properly
6 Recovery tank cover gasket damaged
SQUEEGEE STREAKS
1 Debris under the squeegee blade
2 Worn, nicked or torn squeegee blade
3 Debris build up on the squeegee blade
SWIRL MARKS
1 Running the machine with a dry brush or pad (no cleaning solution)
2 Incorrect brush or pad for the application
3 Debris caught in brush (or pad)
TECHNICAL SPECIFICATIONS
Model BA 430
Model No. 56302200
Current A 40
Voltage, batteries V 24V/2 x 12V
Battery capacity Ah 105
Protection grade IP23
Sound pressure level as per ISO3744 (at operator position) dB (A)/20µPa71
Total weight (with full sol. tank and batteries) lbs / kg 376 / 171
Net weight (with empty tanks and no batteries) lbs / kg 157 / 71
Vibrations at the Hand Controls m/s
2
<2.5m/s
2
