HARD FLOOR KITS
The vacuum shoe can be removed and replaced
with an optional Squeegee Tool (A) for use on hard
fl oors. See Figure 6. Push and hold in the Vacuum
Shoe Release Lever (8) and slide the Vacuum
Shoe (9) off of its mounting pin. Then disconnect
the Recovery Hose (B) from the vacuum shoe and
connect it to Hose Cuff (C) then Squeegee Tool
(A). Attach the squeegee tool to the machine at
the same mounting location used for the vacuum
shoe, simply push the Release Lever (D) and
slide the squeegee tool into place. NOTE: Hard
fl oor applications can require the use of a different
brush. Brush selector guide and part numbers can
be found in the Parts List.
1
12
13
4
7
3a
3b
3
24
27
5
21
15
22
5
