Nilfisk-Advance Clarke EX40 18LX User Manual

9/2015 A - 17 56091181 - EX40 16ST, EX40 18LX
ENGLISH - AINSTRUCTIONS FOR USE
ACCESSORIES / OPTIONS
In addition to the standard components, the machine can be equipped with the following accessories/options, according to the machine’s specifi c
use.
• Brushes with harder or softer bristles
• Upholstery hand tool
• Different wand and hose options
TECHNICAL SPECIFICATIONS (as installed and tested on the unit)
Model Clarke
EX40 18LX
Clarke
EX40 16ST
Model No. 56265505 56265504
Voltage/frequency V/Hz 120 / 50-60 120 / 50-60
Rated Current Amp 14.9 14.5
Protection Class (electrical)
Protection Grade
– – – –
Sound Pressure Level
IEC 60335-2-72: 2002 Amend. 1:2005, ISO 11201
dB(A)/20μPa 68 68
Sound Pressure level - KpA
(IEC 60335-2-72, ISO 11201) Uncertainty
dB(A) 3 3
Vibrations at the Hand Controls (ISO 5349-1) m/s
2
1.8 1.8
Vibrations at the Hand Controls
(ISO 5349-1) Uncertainty
m/s
2
0.2 0.2
Machine Width inch / cm 22.75 / 57.7 19.25 / 48.9
Minimum machine height with adjustable handlebar inch / cm 35.25 / 81.9 32 / 81.3
Maximum machine height with adjustable handlebar
56.5 / 143.5 46.5 / 118
Minimum machine length with adjustable handlebar
29.25 / 74.3 28 / 71.1
Maximum machine length with adjustable handlebar inch / cm 51 / 129.5 48.25 / 122.5
Solution Tank Capacity Gallon / L 12 / 45 9 / 34
Recovery Tank Capacity Gallon / L 12 / 45 7 / 26
Gross Weight* lbs/kg 118 / 53.5 102 / 46.3
Material Composition and Recyclability
Type % of machine weight % recyclable
Aluminum
5% 100%
Electrical / motors / engines - misc
23% 39%
Ferrous metals
3% 100%
Harnesses / cables
1% 83%
Liquids
0% 0%
Plastic - non-recyclable
10% 0%
Plastic - recyclable
10% 100%
Polyethylene
42% 90%
Rubber
7% 33%
