Nilfisk-Advance E145.3 X-TRA User Manual

19
D
Service / Repair.
Assembly of the hose reel - X-TRA models.
1. Make sure that the hose nipple is correct greased before mounting. (Fig 24)
2. Mount the hose into hose reel and connect to the brass part from the internal hose
(Fig 25)
3. Mount the hose reel holder and be sure to assemble the lock clamp correct - MUST
be mounted through both the plastic hose reel holder AND the brass parts. (Fig 26)
Fig. 25
Fig. 24
Fig. 26
