Construction
SM_MC_6P Ver.2.0_2021
24
C
Pic. C5: Pump parts
Piston. Special pi-
ston for 120 bar
models
Washer for spring
Spring. Special return
spring for 120 bar
models
Cylinder block
Thrust collar
Oil seals
Cylinder head
Water inlet
Pressure valve
Secondary seal
Support ring
Back up ring
Primary seal
Header ring
Inlet valve
MC 6P Pump
