Nilfisk-Advance MC 6P Service Manual

Technical data
SM_MC_6P Ver.2.0_2021
5
B
Item number: 107146750
MC 6P-2300/5.0 FA 230/1/60 US
Service manual data
PUMP:
Pressure p
pump
@ Q
nom
bar
155
Pressure p
gun
@ Q
nom
bar
130
Retaining/opening pressure bar
Flow Q
nom
l/min (gpm)
16,8 (4,4)
Suction height dry m (ft.)
1 (3)
Suction height primed m (ft.)
2,5 (8)
Pump type -
NA6
Number of pistons -
4
Pump piston type -
Full Ceramic
Cylinder stroke mm
6,02
Pump oil type -
Castrol Alphasyn T 150
Pump oil amount per pump l
0,73
ELECTRIC:
Electrical data V/ph/Hz
230V/1ph/60Hz
Current @ V
1
A
28
Current limiter A
-
High voltage test voltage V
1500
HV insulation resistance min. MΩ
1
Earth circuit resistance max. Ω
0,2
Speed rpm
1740
Electric diagram item number -
106420563
UNIT DATA:
Nozzle Size -
NT 0680
Max. inlet temperature (suction) °C (°F)
50 (122)
Max. inlet temperature (primed) °C (°F)
70 (158)
Max. inlet temperature (pressure fed) °C (°F)
80 (176)
Max. water inlet pressure bar
10
Min. water inlet pressure bar
1
Max. ambient temperature °C (°F)
40 (104)
Gun Type -
ERGO 2000 STD INCL. SWIVEL NILFISK
Lance primary/secondary -
101406108/None
High pressure hose -
DN10 x 15m - Black
Sound power typeplate dBA
88
Vibration ISO 5349 Lance 1 m/s
2
<1,5; +/-1
Cleaning Impact kg-force
Fuse size A
C 30
Protection Class -
IPX5
Weight - Machine incl. standard acc. kg (lb)
90 (198)
Size - Machine alone LxWxH (mm)
775x570x1020
Detergent suction % (+/-) 6
