ENGLISH INSTRUCTIONS FOR USE
12 SC500 - 9099974000
11/2014
revised 07/2017
BEFORE MACHINE START-UP
WARNING!
When starting the machine, or before operating the One Touch button (43), make sure that there is no foreign
material between the deck and the tank assembly which could obstruct the deck movement. If the machine has
been turned off without lifting the deck, the deck would lift automatically at next machine start-up.
Brush or pad-holder removal/installation
According to the kind of cleaning to be performed, the machine
can be equipped either with the brush (A, Fig. 2) or the pad-
holder (B) with pad (C) together with the appropriate deck.
1. Place the brush (A) or the pad-holder (B) under the brush
deck (26).
2. Place the user key (51) in the key reader (41), then press
the push-button (42) to start the machine.
3. Press the turtle push-button (45) to reduce the driving
speed to idle.
4. Press the One-Touch button (43) to lower the deck onto the
brush.
5. To engage the brush, press the paddle (2), then release
it. If necessary, repeat the procedure until the brush is
engaged.
CAUTION!
Turn the machine speed to idle and slightly press
the paddle, otherwise the machine starts to move.
6. To remove the brush, the deck must be lifted by pressing
the One-Touch push-button (43), then press the release
push-button (44a).
When the display shows the icon (50), wait until the
brush is lowered onto the oor.
A
B
C
Figure 2
P100842
Available brushes and their relevant application guides (suggestions only)
Models 46 GRIT 80 GRIT 180 GRIT 240 GRIT 500 GRIT PROLENE PROLITE UNION MIX
General cleaning:
Concrete
Terrazzo oor
Ceramic tiles/quarrystones
Marble
Vinyl tiles
Rubber tiles
Polishing:
Rubber tiles
Marble
Vinyl tiles
