20
1)
Options / model variants
Original instructions
NEPTUNE 3
9 Further information
9.1 Recycling the cleaner If the cleaner is discarded,
make it unusable immediately
1. Unplug the cleaner and cut
the power cord.
The cleaner contains valuable
materials that should be
recycled. Therefore, make use
of your local waste disposal site.
Contact your local authorities or
your nearest dealer for further
information.
9.2 Guarantee Our general conditions of busi-
ness are applicable with regard
to the guarantee. Subject to
change as a result of technical
advances.
The guarantee is invalidated if
the machine is not operated in
accordance with these instruc-
tions or otherwise abused. The
guarantee is invalidated if the
machine is not serviced as de-
9.3 Technical Data
NEPTUNE 3
3-20
3-30 X
Country variant US US
Possible voltage, V/ph/Frez. V/ph/Hz 120V/1ph/60Hz 220V/1ph/60Hz
Fuse
A20 20
Protection Class IPX5 IPX5
Power rating kW 2,4 4
Working pressure p
IEC
bar (MPa) 1100 (110) 2000 (200)
Water flow Q
IEC
l/h 150 170
Max. water pressure p
max
bar (MPa) 250 (25) 250 (25)
Water flow Q
max
l/h 160 180
Max. water inlet temperature
Intake-Pressure operation
°C (°F) 40 (104) 40 (104)
Heating power input BTU 167200 211600
Max temperature t
max
,water °C (°F) 99 (210) 99 (210)
Max temperature t
max
,steam °C (°F) 150 (302) 150 (302)
Max. water inlet pressure bar (MPa) 10 (1) 10 (1)
Max. dry suction height m - -
Dimensions, l x w x h mm 1053x685x760 1053x685x760
Weight of cleaner kg 125 126
Sound pressure level L
PA
at a
distance of 1 m
dB(A) 73,1 73,1
Guarantied sound power level
L
WA
dB(A) 89 89
Vibration ISO 5349 m/s² <2,5; +/-1 <2,5; +/-1
Recoil forces, lance1 / lance 2 N 16,3 / - 27,4 / -
Oil quantity l 1,2 1,2
Oil type SAE 15W-40 Agip Rotra
Specifications and details are subject to change without prior notice.
