10
addition, provide sufficient space around the unit for servicing and maintenance operations.
⑥ The unit must not be installed in an area exposed to oil, flammable gases, corrosive
products, sulfur compounds or close to high frequency equipment.
⑦ To prevent external damage to the unit, do not install it near a road or track.
⑧ To avoid causing nuisance to neighbors, make sure the unit is installed in an area that is not
sensitive to noise.
⑨ Keep the unit out of the reach of children.
⑩ Installation space:
Unit: mm
Do not put anything less than 1500mm (5ft) in front of the heat pump.
Leave 500mm (2ft) of empty space on the sides and back of the heat pump and free space for
air circulation above
Do not leave any obstacles above or in front of the device!
3.3.4 Installation Layout
The installation diagram is shown in the following figure –
Pool → Pump → Filter → Heat Pump → Sanitizer → Return to Pool:
