Nirvana DISTINCTION SIM50IV - Main Parts of the Unit

5
2.3. Main Parts of the Unit
Model: SIM50IV
1
Top cover
8
Fan motor
15
4-way valve
2
Electrical box cover
9
Fan blade
16
Wired controller
3
Electrical box
10
Front plate
17
Right handle
4
Left Grid Plate
11
Fan shield
18
Titanium heat exchanger
5
Motor support
12
Evaporator
19
Right plate
6
Middle partition plate
13
Ambient temp. sensor
20
Compressor
7
Fixed support
14
Reactor
21
Chasis
